Audio Outputs
(1) XLR output pair (main left/right,balanced)
(1) RCA output pair (main left/right, unbalanced) (1) 1 1/4” (6.35 mm) stereo output (headphones) (1) 1/8” (3.5 mm) stereo output (headphones)
Audio Inputs
(1) 1 1/4” (6.35 mm) microphone input
Other
(2) USB port (for USB drives)
(1) USB port (to computer)
(1) SD card slot
(1) power adapter input (for charging and wired use)
Main Outputs
Frequency Response: 20 Hz – 20 kHz +/- 1 dB Dynamic Range: > 114 dB (A-weighted) Signal-to-Noise Ratio: > 94 dB (A-weighted)
Headroom
Mic: > 16 dB Outputs: > 16 dB
Channel Separation: < -110 dB (1 kHz, unity)
T.H.D.
Line: < 0.01% (1 kHz, unity) Microphone: < 0.05% (1 kHz, unity)
Speakers
Frequency Response: 20 Hz – 20 kHz +/- 1 dB
Analog Input
Microphone: -40 dBu (unity) / -60 dBu (minimum)
Analog Output
Master, Balanced: +20 dBu (maximum) / +4 dBu (unity) Master, Unbalanced: +16 dBu (maximum) / 0 dBu (unity) Headphone Output: < 30 mW
Connection: DC, Center Positive Voltage: 12.0 V 3.0 A
Built-In Rechargeable Battery
Width x Depth x Height: 22.3” x 11.2” x 2.9” / 566 x 284 x 74 mm
