Regular price Rp. 45.760.000,00 Rp. 29.999.000,00 Sale

Overview

MP2015 Rotary Control DJ Mixer. Control, sound, reliability and durability distinguish Rane’s new techno house club mixer for high-end audio systems. Born from a legacy of rotary club mixers beginning in 1971 with Rudy Bozak’s CMA-10-2DL, on to 1982 and UREI’s 1620, then in 1999 Rane’s MP2016/XP2016 combo, and now in 2015, the MP2015 represents the next revival and evolution. This mixer has an analog soul with a digital heart. With over 40 years of rotary mixer experience to draw on, along with collaboration and input from the world’s best techno house DJs, the MP2015 is the best mixer produced by Rane—ever. There are no compromises in the design. It has the best sound, the best features, the best feel, and the best reliability and durability. Sound Quality A world-class leader in performance, this mixer is designed for playback of High-Resolution Audio (HRA) 24-bit studio master quality sources. Its sonic signature has no equal, satisfying the most stringent vinyl purists. And the dynamics are perfect for DJs that appreciate the uncompressed sound of WAV and FLAC files. Professional high-end sound quality begins and ends with the audio signal converters. The MP2015 uses premium performance Audio 4 Pro delta-sigma modulator converters by AKM [Asahi Kasei Microdevices Corporation] that meet the highest sound quality standards of recording studios. Studio-Quality Phono Preamps, and S/PDIF for CDJs The Phono-CD (or any line-level source) analog inputs feature gold RCA connectors and are true studio-quality preamplifiers providing EMI[1], RFI[2] and transient overvoltage protection against ESD[3]. The circuitry provides low noise, high gain-bandwidth, low harmonic distortion, fast slew rate and high output current. The phono RIAA filter accuracy measures +0.1/-0.2 dB from perfect. Included are 18 Hz high-pass infrasonic (rumble) filters with steep 18 dB/octave slopes and ultrasonic filters beginning roll-off at 50 kHz at a 12 dB/octave rate. A zero-di...

Key features

Superior build

  • Robust 4-channel Rotary Mixer with solid chassis and classic wooden design, pro XLR and TRS Outputs and AKM premium performance Audio 4 Pro delta sigma modulator converters.

Advanced sonic control

  • Craft and mould your mix with powerful 3band Isolator EQ's with fully adjustable crossover points. Command frequency control with the variable resonance parameter sweepable filter control.

No compromise

  • MP2015 is the best mixer produced by RANE - ever. There are no compromises in the design. The best sound, the best features, the best feel, and the ultimate in reliability and durability. Serato DJ Pro, Traktor & Virtual DJ compatible.

Sweep Filters

  • Each of the four input channels and the Submix channel features a unique three-position toggle selector switch. Choose between LP, HP or L-H combo. All have steep 24dB/octave (4th-order) slopes and are sweepable.

Submix

  • This unique input channel provides grouping for any number of inputs for easy multi-source mixing. Additionally, this becomes another input to make a 5 channel mixer.

3-Band Full-Cut Tone Controls

  • All input channels and the Submix channel have exceptional three-band tone controls. These are 12 dB/octave (2ndorder) Linkwitz- Riley, full-cut filters (kill) with selectable crossover points of 150Hz/6.0 kHz or 300Hz/3.0kHz.
Specifications
Analog Inputs
    • Four Analog Deck Inputs: Each is Phono-CD-S/PDIF switchable
      • ....Analog Stereo RCA jacks: Phono (RIAA) or CD (line-level)
  • ........Phono Response: RIAA +0.1/-0.2 dB, Gain: 31 dB at 1 kHz, Butterworth 3rd-order Infrasonic (rumble) and 2nd-order Low-pass Filters
  • ........Max Phono Input: 126 mV
  • ........Max Line Input: 4 Vrms, all unbalanced inputs
  • Analog Aux Input: Line Level, stereo unbalanced RCA jacks
  • Session Analog Input: Line Level, stereo unbalanced RCA jacks
S/PDIF
  • Deck Input S/PDIF RCA jacks: Input 16-bit or 24-bit PCM only
    • ........Dynamic range of 128 dB with ultra low jitter and 16:1 SRC conversion range.
  • Session S/PDIF Input / Output: RCA jacks (Dynamic range of 128 dB)
    • ....Input 16-bit or 24-bit PCM only, sample Rate 16 kHz to 144 kHz
ADCs
  • 24-bit @ 44.1, 48, or 96 kHz
DACs
  • 24-bit @ 44.1, 48, or 96 kHz
Dynamic Range
  • Digital/USB Input to Line Output: 116 dB A-weighted
  • Line Input to Digital/USB Output: 116 dB A-weighted
  • Line Input to Line Output: 113 dB A-weighted
Digital Signal Processing
  • 32-bit floating point.
USB Audio
  • Seven stereo record, five stereo playback, each port, 24-bit PCM @ 44.1 kHz, 48 kHz or 96 kHz.
    • Class-compliant, no driver needed for Mac OS X*.
    • ASIO driver provided for Windows 7 and higher.
  • *Firmware update required for support on macOS 10.12 Sierra and higher.
FlexFX
  • Stereo unbalanced ¼" TS (tip-sleeve) jacks, Send and Return.
Mic Input
  • Balanced ¼" TRS & XLR combo jack with Mic / Line switch and +48V Phantom Power switch.
Line Outputs
  • Main is on balanced XLR jacks
  • Booth is on balanced TRS 1/4" jacks
  • Session is on unbalanced RCA line level or S/PDIF digital RCA jacks
  • FlexFX Loop Send is unbalanced RCA jacks.
    • ....Frequency Response: 20 Hz to 20 kHz ±0.25 dB
    • ....Unbalanced jacks (Session & FlexFX): Max 4 Vrms
    • ....Balanced jacks (Main & Booth): Max 8 Vrms
THD+N
  • 0.0009%
Internal Universal Power Supply
  • 100 to 240 VAC, Max 20 W, 50 Hz to 60 Hz.
Unit Size
  • 35.5 cm x 33.3 cm x 8.3 cm [14˝ H x 13.1˝ W x 4.3˝ D (includes knobs)]
  • Weight: 5.7 kg or 12.6 lb.
Shipping Size
  • 19.7 cm x 38.1 cm x 49 cm [7.75˝ H x 15˝ W x 19.25˝ D]
  • Weight: 7 kg or 15 lb.
