Yamaha MGP16X
Yamaha MGP16X
Yamaha MGP16X

Yamaha MGP16X

Regular price Rp. 7.480.000,00 Sale

Overview

The Yamaha MGP16X 16-Channel Premium Mixing Console is the result of the call for a small format sound reinforcement console with a feature set that meets the demands of today's touring bands, performance groups, live venues, houses-of-worship, town halls and more. The console features a total of 16 input channels with 8 mono inputs, and 4 stereo inputs, dual effects processor, 1-knob compression, stereo hybrid channels and optional control / audio playback from Apple iPads and iPhones.

The front-end features 10 of Yamaha's breakthrough D-Pre microphone preamps, featuring an inverted Darlington circuit design. The result is a transparent, warm and musical audio character unique to the MGP16X. The mixer's X-pressive EQ section delivers precise settings, steep shelving and musical frequency contouring. A powerful Dual Digital Effects processor employs Yamaha REV-X reverbs and SPX series digital multi-effects. An additional feature unique to the MGP16X is its dedicated stereo Digital Hybrid channels.

Two stereo channels feature extensive DSP underneath the familiar analog controls. The Digital Hybrid channels feature Priority Ducker for prioritizing announcements and other signals, a Leveler for global level control and a Stereo Image feature that adjusts the width of stereo tracks, and allows for a much more comfortable listening experience (ideal for backing tracks and intermission music breaks). The Yamaha MGP16X features a USB iPod and iPad connection. Not only can the console playback audio from these devices, Yamaha's free MGP editor app allows for extensive control and editing of many of the console's features and parameters, directly from your Apple iPhone or iPad. Thanks to its integrated rack ears, the MGP16X can be rack mounted.



Key features
  • Small-Format Sound Reinforcement
  • 8 Mono Input Channels
  • 4 Stereo Input Channels
  • D-Pre Microphone Preamplifiers
  • Dual Digital Effects Engine
  • X-pressive EQ Section
  • 1-Knob Compressors
  • 2 Digital Hybrid Stereo Channels
  • Control & Playback with iPhone & iPad
  • Integrated Universal Power Supply

Specifications
Channels 16 Line inputs (8 mono and 4 stereo)
Groups 4 Group buses + ST bus
AUX Input 2 Aux Sends + 2 FX Sends
Compressor Compressor CH1-8, HPF (100Hz 12dB/oct)
EQ Section Mono: ±15dB(Max.), High 8kHz shelving/ Mid 250Hz-5kHz peaking(CH1-8,9-16)/ Low 125Hz shelving
Stereo:±15dB(Max.):High 8kHz shelving/ Mid 2.5kHz peaking(CH9-12)/ Low 125Hz shelving
Effects FX1:REV-X(8 Program, Parameter control),
FX2:SPX (16 Program, Parameter control)
Microphone Inputs 10,(100Hz 12dB/oct)
Phantom Power 48V phantom power per channel
Line Inputs Line: 8mono + 4stereo
Channel insert in: 8
Return: 1 stereo
2TR IN: 1 stereo
Digital I/O USB audio USB in: iPod, iPhone exclusive
THD 0.02% (20Hz-20kHz@ +14dBu)
Frequency Response +0.5/-1.0dB 20Hz - 20kHz, refer to the nominal output level @1kHz
EIN -128 dBu (20Hz-20 kHz, Rs=150Ω, input gain = maximum)
Residual Output Noise -102 dBu (20Hz-20 kHz, Rs=150Ω, input gain = maximum)
Crosstalk -74dB @ 1kHz
Power Requirements 100-240V 50Hz/60Hz
Consumption: 55W
Dimensions (WxHxD) 17.59 x 5.62 x 19.48" (447 x 143 x 495mm)
Weight 19.84lb (9kg)
Packaging Info
Package Weight 26 lb
Box Dimensions (LxWxH) 24 x 24 x 10"

In the Box

  • Yamaha MGP16X 16-Channel Premium Mixing Console
  • AC Power Cord
  • Owner's Manual
  • Limited 1-Year Warranty
